sp8 8-inch full range speaker




applications

feature

outdoor

unique hdwt high density waterproof technology

all-weather

cp anticorrosive metal treatment technology

waterscape

the surface of component is wrd waterproof adhesive

theatre

uce point sound source uniform energy cover technology

multi-function hall

odc point source directivity optimization control technology

conference room

the frequency network based on the unit features makes the overall sense of hearing smoother

church


fill system




technical specification

frequency respond

80 hz ~ 18 khz (±3 db)55 hz ~ 20 khz (-10 db)

nominal coverage(-6db)

80°(h) 80°(v) constant directivity

sensitivity

95 db spl

powerating(aes)

250 w(continuous);1000 w(peak)

nominal impedance

8 ω

maximum spl

118 db(continuous);124 db(peak)

drivers

hf  1 x 34 mm compression driver

lf  1 x 8" woofer



physical data

dimension( h x w x d)

486x 259 x 268 mm

weight

10 kg

connectors

2 x wp4 waterproof connectors

speaker cables

1-2

materials

ap acoustics professional birch plywood

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

level of protection

ip56
