outdoor

unique hdwt high density waterproof technology

all-weather

cp anticorrosive metal treatment technology

waterscape

the surface of component is wrd waterproof adhesive

theatre

patented technology of cwg plane wave generator

multi-function hall

spct phase correction patent technology

touring performance

small single-way drive and full-frequency system

church

neodymium high-sensitivity driver, maximum headroom

small enclosure, light, high spl and volume ratio

frequency respond

60hz ~ 18 khz (±3db)；50 hz ~ 20 khz (-10db)

nominal coverage(-6db)

90°(h) 10°(v)adjustable

sensitivity

hf:110 db spl；lf:99 db spl

powerating(aes)

hf:80 w(continuous);320 w(peak)

lf:700 w(continuous);2800 w(peak)

nominal impedance

16 ω

maximum spl

hf:129 db(continuous);135 db(peak)

lf:127 db(continuous);133 db(peak)

drivers

hf: 1×3"(75 mm voice coil)driver

lf: 2×10"(65 mm voice coil)woofer

dimension( h x w x d)

339×1069×404 mm

weight

38kg

connectors

2 x wp4 connectors

speaker cables

lf:1-2 ,  hf:3-4

materials

aabp composite aluminum alloy birch board box

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

rigging

0~10degree,each 1 degree adjustable

level of protection

ip56
