sb18—subwoofer

365现金网官网的产品展示图 pla谱莱声音响(2016年版)s18.jpg


application

feature

touring performance

100mm voice coil, high transient response woofer

theatre

thick and elastic hearing

stadium

vented, horn preposition design




technical specification

frequency respond

30 hz ~ 180 hz(±3 db) ;  25 hz ~ 250 hz(-10 db)

nominal coverage(- 6 db)

omnidirectional

sensitivity(@1w/1m)

100 db spl

powerating(aes)

1200 w

nominal impedance

8 ω

maximum spl

130 db (continuous) 136 db (peak)

drivers

1 x 18"100 mm voice coil)  subwoofer




physical data

dimension( h x w x d)

750×561×880 mm

weight

48kg

speaker cables

1-2 signal input & loop

connectors

2 x wp4 connectors

materials

18 mm24 mm ,30 mm birch plywood

finish

black water paintings

grille

porous steel mesh with black spraying
