s10

365现金网官网的产品展示图 pla谱莱声音响(2016年版)s10.jpg


application

feature

conference room

1×10" long throw foam subwoofer

background music

bass reflex design




technical specification

frequency respond

40 hz ~180 hz (±3 db);  30 hz ~250 hz(-10 db)

nominal coverage(- 6 db)

omnidirectional

sensitivity(@1w/1m)

90 db spl

powerating(aes)

250 w

nominal impedance

8 ω

maximum spl

114 dbcontinuous120 dbpeak

drivers

1 x 10"65 mm voice coil)  subwoofer






physical data

dimension( h x w x d)

390×320×385.8 mm

weight

14kg

speaker cables

1 1-signal input & loop

connectors

2 x nl4mp neutrik speakon connectors

materials

15 mm high density board

finish

brown water paintings

grille

porous steel mesh with black spraying
