s18


365现金网官网的产品展示图 pla谱莱声音响(2016年版)s18.jpg


application

feature

disco

vented subwoofer

club and kuba

18" direct- radiation driver


heat resisting 4" (100mm)voice coil


large-scale vented design to reduce airflow noise




technical specification

frequency respond

32 hz ~ 180 hz(±3 db) ;  30 hz ~ 250 hz(-10 db)

nominal coverage(- 6 db)

omnidirectional

sensitivity(@1w/1m)

99 db spl

powerating(aes)

1200 w

nominal impedance

8 ω

maximum spl

129 db (continuous) 135 db (peak)

drivers

1 x 18"100 mm voice coil)  subwoofer






physical data

dimension( h x w x d)

706×561×604.5 mm

weight

42kg

speaker cables

1 1-signal input & loop

connectors

2 x nl4mp neutrik speakon connectors

materials

18 mm24 mm birch multi-plywood

finish

black or brown water paintings

grille

porous steel mesh with black spraying
