es-06 emergency switcher




whole series of primary standby and switching system. designed for the audio system that can flexibly switch the primary standby input signal.

design of all-standard xlr jack, user caneasily switch the input signal through the front panel switch. primary standby system switcher for professional broadcast quality, high-demand audio metrics available, use the first grade of broken electrical appliances, provide audio level signal processing up to 24dbu.


front panel setting

toggle switch


rear panel setting

i/p-a signal input

i/p-b signal input

o/p signal output

power1/2 dual power supply input

control external remote interface

cascade cascade connection control interface


※es-08 is 8-channel two-channe signal input.

※broadcast-level audio quality.

※working level up to 24dbu.

※specially design for the radio and television system.

※standard 2u-19 inch rack airframe.

※front and rear panels can also be installed on the rack.

※highly integrated, rugged all-metal organism.

※military indicators accessories manufacturing.



specifications



frequency response0db 20hz ~ 20khz 0db
input levelmax 40dbu
total harmonic distortion degree0.00035%(0 dbu 1khz)
loss attenuation

0db 600 ohm load (in most high impedance input devices, can be considered without attenuation loss)

output short circuit0db
size483(w)x88(h)x328(d)mm
weight3.9kg
