microphone splitter—ms16 pro
specifications:
ms 16 pro equivalent to 16pcs ms 01 pro;
16-channel balanced input. 16pcs -20db switch;
16-channel direct output, 32-channel isolating transformer output with 32 ground lift switches;
each output able to ppd supply.
ms microphone splitter series, is designed from changing the microphone layout flexibly to work with audio system. with imported swiss neutrik of the card lennon socket, the design of the full standard lennon terminal block, user can easily change and convert input and output microphone location or arrangement .
microphone distribution system for professional broadcast quality, high-end audio metrics available, selection of the highquality of the audio transformer, provide audio level signals handling up to 26dbu.
microphone splitter has one channel input, balanced swiss neutrik 3-core xlr female jack, equipped with -20db switch, each channel of the microphone distributor is provided with three sets of output respectively, one sets output directly, 2 sets of isolated transformer output. the output (a and b) also has a ground separation selector switch, to solve the noise caused by ground circuit, when switch on, the ground will be set apart. while switch down, the ground will be set to connect, in addition, a phantom power supply direct circuit (ppd phantom power direct patent technology) provides phantom power for input microphone.
features:
※16-channel microphone input, three sets of 16-channel microphone (48-channel) output.)
※ broadcast-level audio quality.
※ working level up to 26dbu .
※ ppd phantom power direct patent technology: each set of outputs can simultaneously provide phantom power for capacitive microphone work.
※ specially designed for rental market.
※ broadcast grade audio isolating transformer output.
※ one-channel direct output, two-channel ground output can be independently disconnected set selection .
※ standard 2u-19 inch rack frame.
※ front and rear panels can also be installed on the rack.
※ highly integrated, rugged all-metal organism.
※ military indicators accessories manufacturing.
※ each channel of the distributor is provided with three sets of outputs: 1 sets of direct output and 2 sets of isolated transformer outputs.
※ independent ground lift selection.
frequency response | -0.2db,20hz~20khz,0db |
|
input level | max 26dbu to 50hz | |
total harmonic distortion degre | 0.005%(0dbu 1khz) | |
attenuation loss | -2.3db to 600ωload (in most high impedance input devices,can be considered without attenuation loss) | |
output short-circuit loss | -1.4db | |
set up | ground selection of output a and output b of isolating transformer xlr male jack, isolation transformer output b and direct output microphone fantasy power selection | |
size | 100mm(l)×98mm(w)×52mm(h) | |
weight | ms 16 pro 6.5kg |
