ms microphone splitter—ms01 pro

specifications:

one-channel balanced input. one pcs -20db switch;

one-channel direct output, two-channel isolating transformer output with two ground lift switches;

each output able to ppd supply.

features:

ms microphone splitter series, is designed from changing the microphone layout flexibly to work with audio system. with imported swiss neutrik of the card lennon socket, the design of the full standard lennon terminal block, user can easily change and convert input and output microphone location  or arrangement .

microphone distribution system for professional broadcast quality, high-end audio metrics available, selection of the highquality of the audio transformer, provide audio level signals  handling up to 26dbu.

microphone splitter has one channel input, balanced swiss neutrik 3-core xlr female jack, equipped with -20db switch, each channel of the microphone distributor is provided with three sets of output respectively, one sets  output directly, 2 sets of isolated transformer output. the output (a and b) also has a ground separation selector switch, to solve the noise caused by ground circuit, when switch on, the ground will be set apart. while switch down, the ground will be set to connect, in addition, a phantom power supply direct circuit (ppd phantom power direct patent technology) provides phantom power for input microphone.

technology parameters:

※1 input / 3 output.

※ 0db / -20 db switch.

※ ppd phantom power direct patent technology.

※ broadcast-level audio quality.

※ working audio level up to  26dbu.

※specially designed for rental market.

※ broadcast grade audio isolating transformer output.

※ one-channel direct output, two-channel ground output can be independently disconnected set selection .

※ highly integrated, rugged all-metal organism.

※ military indicators accessories manufacturing.

※ independent ground lift selection.
