touring performance

large-scale ,bi-amp, two-way line array system

stadium

thick and elastic bass, clear high frequency

theater

the same size and hanging parts as ls212

frequency respond

50 hz ~ 16 khz(±3 db)；40 hz ~ 18 khz(-10 db)

nominal coverage(-6db)

90°(h) adjustable

sensitivity

hf:113 db spl hf:101 db spl

powe rating(aes)

hf/lf:80/500 w(aes)

nominal impedance

hf/lf:16/16 ω

maximum spl

hf:132/138 db lf:128/134 db

drivers

lf:2 x 15" woofer

hf:1 x 3" neodymium compression driver

dimension( h x w x d)

367×1000×550 mm

weight

56 kg

connectors

2 x wp4 connectors

speaker cables

1-2 …lf，3-4 …hf

materials

18 mm birch plywood

finish

black water paintings

grille

porous steel mesh with black spraying

rigging

0、1、2、3、4、5、6、7.5°degree

adjustable
