touring performance

small bi-amp system

theatre and multifunction

hall

neodymium high-sensitivity driver,

maximum headroom

church

small enclosure, light, high spl and

volume ratio

frequency respond

60 hz~18 khz(±3 db) ; 50 hz~20 khz(-10 db)

nominal coverage(- 6 db)

90°(h)adjustable

sensitivity(@1w/1m)

hf:112 db (2 khz~16 khz)

lf:103 db (500 khz~ 2 khz)

powerating(aes)

hf/lf: 80 /350 w(aes)

nominal impedance

hf/lf: 16/16 ω

maximum spl

hf/lf: 16/16 ω

drivers

lf:1 x 10" woofer

hf:1 x 3" neodymium compression driver

dimension( h x w x d)

279.5×580×392.5 mm

weight

22.5kg

speaker cables

1-2 …lf，3-4 …hf

connectors

2 x wp4 connectors

materials

15 mm，18 mm baltic birch plywood

finish

black water paintings

grille

porous steel mesh with black spraying

rigging

0、1、2、3、4、5、7.5、10° degree

adjustable
